Amplifiers
Intra
The TIDAL Intra is a high-end stereo power amplifier designed around pure signal amplification without added coloration or unnecessary complexity. Its dual-mono architecture physically separates the two stereo modules, with each power supply dedicated to a single channel in stereo operation. The amplifier can also operate in bi-amping or bridged mono configurations, making it exceptionally versatile. A fully discrete Class-A front end is combined with a Class-D output stage, derived from technology developed for the TIDAL for Bugatti Royale project.
Technical Specifications
- Feature: Dual-stereo power amplifier
- Feature: 4 amplification channels
- Primary stereo mode: 2 x 340 W at 8 Ω , 2 x 670 W at 4 Ω
- Dual-stereo bi-amping mode: 4 x 290 W at 8 Ω, 4 x 540 W at 4 Ω
- Dual-mono BTL mode: 2 x 1,180 W at 8 Ω, 2 x 1,830 W at 4 Ω
- Feature: Fully discrete Class-A front-end amplifier
- Feature: Class-D output stage
- Feature: Completely DC-coupled signal path
- Feature: No capacitors in the signal path
- Feature: 4 x balanced XLR inputs
- Feature: TIDAL remote power on/off input
- Feature: Protection against temperature, over-current, DC, and high-frequency conditions
- Dimensions: 44 x 13 x 39 cm / 17.3 x 5.1 x 15.3"
- Weight: 12 kg / 27 lbs.
